Functional Binding Equipment

FB798

Binding Form : Double Wire ,Plastic Comb, Spiral Coil
Max. Binding Thickness : 50mm (Plastic Comb)
Dimension : 410x280x170mm
Net Weight: 17.5kgs

FB8808

Binding Form : Double Wire ,Plastic Comb
Binding capacity : 30mm Ring Plastic Comb
50mm Ellipse Plastic Comb
25.4mm Double Wire
Punching capacity: 20sheets(80g)
Max. Binding Width: random for Double Wire
320MM for Plastic Comb
Design of Section: 3.0x8.0mm Plastic Comb
4.0x4.0mm Double Wire 3:1
Hole Distance: 14.3mm 24 holes
8.47mm 40 holes
Side Margin Control: 2.5-6.5mm
Disengagement dies: 12 pieces Plastic Comb
20 pieces Double Wire 3:1
Power: (220V 50HZ) / (110V 60HZ)
Dimension : 460x600x250mm
Weight: 35kgs

FB0608B

Binding Form : Double Wire ,Plastic Comb
Max. Binding Thickness : 25.4mm Plastic Comb
Max. Punching Thickness : 25 pages (80g)
Max. Binding Width : Arbitrary
Hole Distance : 2:1 (12.7mm) 27 holes
3:1 (8.47mm) 40 holes
Adjustable Margin : 2.5—6.5mm
Design of Section : 2:1 4.0x5.5mm
3:1 4.0x4.0mm
Disengagement dies : 2:1 13 pieces
3:1 20 pieces
Power : (220V 50HZ) (110V 60HZ)

FB0608R

Binding Form : Double Wire ,Plastic Comb
Max. Binding Thickness : 25.4mm Double Wire
Max. Punching Thickness : 20 pages (80g)
Max. Binding Width : Arbitrary
Hole Distance : 2:1 (12.7mm) 27 holes
3:1 (8.47mm) 40 holes
Adjustable Margin : 3mm
Design of Section : Ф6MM(2 :1) Ф4.5MM(3 :1)
　

FB0608RN
